    Class2 12vdc 100w power supply 110v 220v 12v ac/dc led transformer

    Ask Lasest Price
    Brand Name : YHY
    Model Number : YHY-12008000
    Certification : UL, CCC, PSE, KC, CE, SAA
    Price : USD10-15 per piece
    Payment Terms : T/T, Western Union, PayPal
    Supply Ability : 100000pcs per week
    Delivery Time : 10-15 work days
    • Product Details
    • Company Profile

    Class2 12vdc 100w power supply 110v 220v 12v ac/dc led transformer


    Input Voltage RangeVAC100-240Vac 50/60Hz
    Input Current(Max)A2.5A(100VAC Input)
    Power Factor-Meets EN61000-3-2
    Temperature Coefficient±0.05%/℃
    Voltage Accuracy%±2%
    Adjustment Range-None
    Min. LoadANone
    Total Regulation-±5%
    Ripple & NoisemV120mV
    Short Circuit Protection%Continuous - hiccup mode
    Over Voltage Protection110-150% of nominal (Cycle input power to reset)
    Efficiency at Average Load-88% min
    Operation Temperature-0 to +60℃, derating linearly to 50% load above 40℃
    Storage Temperature--10 to +85℃
    Humidity (non condensing)-10-90% RH
    Cooling-Convection
    Withstand Voltage-Input to Ground 1.5kVAC, Input to Output 3kVAC
    (Output is connected to Ground)
    Vibration (non condensing)-23.52m/s2 (10 - 55Hz: constant sweep 1 min X, Y, Z for 1 hour)
    Shock-< 196.1 m/s2 (20G)
    Safety Agency Certifications-UL62368,UL1310,UL60950-1, EN609501-1, IEC60950-1, CE Mark
    DOE Regulation-VI
    Off-Load Power ConsumptionmW<210mV
    Conducted & Radiated EMI-EN55023-B, FCC Class B
    Immunity-EN55024

    Class2 12vdc 100w power supply 110v 220v 12v ac/dc led transformer


    Output Ratings
    ModelOutputOutput Max.Power Max.DOE VI
    (V)(A)(W)
    YHY-050080005840
    YHY-060080006848
    YHY-090080009872
    YHY-1000800010880
    YHY-12008000128100
    YHY-15006600156.6100
    YHY-18005500185.5100
    YHY-19005200195.2100
    YHY-20005000205100
    YHY-24004000244100
    YHY-30003300303.3100
